form land
tile=property y=90 w=85 h=350 size=40 bg=white section=press
tile=rectangle name=c1 x= 10
tile=rectangle name=d1 x=100
tile=rectangle name=e1 x=190
tile=rectangle name=f1 x=280
tile=rectangle name=g1 x=370
tile=rectangle name=a1 x=460
tile=rectangle name=b1 x=550
tile=property size=32 h=60 y=440 color=black bg=transparent visible=#visible section=""
tile=text text=c1 x= 25
tile=text text=d1 x=125
tile=text text=e1 x=215
tile=text text=f1 x=305
tile=text text=g1 x=395
tile=text text=a1 x=485
tile=text text=h1 x=575
tile=property y=90 w=58 h=180 size=35 bg=black section=press
tile=rectangle name=cs1 x= 70
tile=rectangle name=ds1 x=160
tile=rectangle name=fs1 x=345
tile=rectangle name=gs1 x=435
tile=rectangle name=as1 x=525
tile=property size=32 h=60 y=20 bg=transparent visible=#visible section=""
tile=text text=c1# x= 70
tile=text text=d1# x=160
tile=text text=f1# x=340
tile=text text=g1# x=430
tile=text text=a1# x=520
tile=property y=90 w=85 h=350 size=40 bg=white section=press
tile=rectangle name=c2 x= 640
tile=rectangle name=d2 x=730
tile=rectangle name=e2 x=820
tile=rectangle name=f2 x=910
tile=rectangle name=g2 x=1000
tile=rectangle name=a2 x=1090
tile=rectangle name=b2 x=1180
tile=property size=32 h=60 y=440 bg=transparent visible=#visible section=""
tile=text text=c2 x=670
tile=text text=d2 x=760
tile=text text=e2 x= 850
tile=text text=f2 x= 940
tile=text text=g2 x=1020
tile=text text=a2 x=1110
tile=text text=h2 x=1200
tile=property y=90 w=58 h=180 size=35 bg=black section=press
tile=rectangle name=cs2 x=700
tile=rectangle name=ds2 x=790
tile=rectangle name=fs2 x=965
tile=rectangle name=gs2 x=1055
tile=rectangle name=as2 x=1145
tile=property size=32 h=60 y=20 bg=transparent visible=#visible section=""
tile=text text=c2# x= 710
tile=text text=d2# x= 790
tile=text text=f2# x= 980
tile=text text=g2# x=1060
tile=text text=a2# x=1140
tile=property bg=transparent s=30 visible=1 color=black section=""
tile=button section=save x= 240 y=650 w=500 text=@recording section=save
tile=button section=play x= 760 y=650 w=500 text=@playback section=play
tile=button section=help x=20 y=650 w=200 text=@help section=help
end form
section save
message "in developing"
end
section play
message "in developing"
end
section help
if #help_mode==1
#help_mode=0; #help=@help; #visible=0; #color=black
else
#help_mode=1 ; #help=@help; #visible=1; #color=red
endif
draw form=#form
end
section press
// message #_selected_name
#sound= $concate(#_selected_name+".wav")
sound mode=start file= #sound directory=#_directory_sound_examples
end section
section back
call script=examples_apps2
end section
end scene
LIST OF EXAMPLES
Die bereitgestellten Screenshots können geringfügig von den tatsächlichen Ergebnissen der Skripte abweichen.
